#include <ware/SimulationContributorWare.hpp>
openfluid::ware::SimulationContributorWare::SimulationContributorWare | ( | WareType | WType | ) | [inline, protected] |
virtual openfluid::ware::SimulationContributorWare::~SimulationContributorWare | ( | ) | [inline, virtual] |
bool openfluid::ware::SimulationContributorWare::OPENFLUID_AddChildParentConnection | ( | openfluid::core::UnitClass_t | ClassNameChild, |
openfluid::core::UnitID_t | IDChild, | ||
openfluid::core::UnitClass_t | ClassNameParent, | ||
openfluid::core::UnitID_t | IDParent | ||
) | [protected] |
Adds a child-parent connection between two units
[in] | ClassNameChild | class name of the "child" unit |
[in] | IDChild | ID of the "child" unit |
[in] | ClassNameParent | class name of the "parent" unit |
[in] | IDParent | ID of the "parent" unit |
bool openfluid::ware::SimulationContributorWare::OPENFLUID_AddChildParentConnection | ( | openfluid::core::Unit * | ChildUnit, |
openfluid::core::Unit * | ParentUnit | ||
) | [protected] |
Adds a child-parent connection between two units
[in] | ChildUnit | pointer to the "child" unit |
[in] | ParentUnit | pointer to the "parent" unit |
bool openfluid::ware::SimulationContributorWare::OPENFLUID_AddFromToConnection | ( | openfluid::core::UnitClass_t | ClassNameFrom, |
openfluid::core::UnitID_t | IDFrom, | ||
openfluid::core::UnitClass_t | ClassNameTo, | ||
openfluid::core::UnitID_t | IDTo | ||
) | [protected] |
Adds a from-to connection between two units
[in] | ClassNameFrom | class name of the "from" unit |
[in] | IDFrom | ID of the "from" unit |
[in] | ClassNameTo | class name of the "to" unit |
[in] | IDTo | ID of the "to" unit |
bool openfluid::ware::SimulationContributorWare::OPENFLUID_AddFromToConnection | ( | openfluid::core::Unit * | FromUnit, |
openfluid::core::Unit * | ToUnit | ||
) | [protected] |
Adds a from-to connection between two units
[in] | FromUnit | pointer to the "from" unit |
[in] | ToUnit | pointer to the "to" unit |
void openfluid::ware::SimulationContributorWare::OPENFLUID_AddUnit | ( | openfluid::core::UnitClass_t | ClassName, |
openfluid::core::UnitID_t | ID, | ||
openfluid::core::PcsOrd_t | PcsOrder | ||
) | [protected] |
Adds a unit to the set of units if not already exists
[in] | ClassName | class name of the added unit |
[in] | ID | ID of the added unit |
[in] | PcsOrder | Process order of the added unit |
void openfluid::ware::SimulationContributorWare::OPENFLUID_AppendEvent | ( | openfluid::core::Unit * | UnitPtr, |
openfluid::core::Event & | Ev | ||
) | [protected] |
Appends an event on a unit
[in] | UnitPtr | a Unit |
[in] | Ev | the event to append |
void openfluid::ware::SimulationContributorWare::OPENFLUID_AppendVariable | ( | openfluid::core::Unit * | UnitPtr, |
const openfluid::core::VariableName_t & | VarName, | ||
const openfluid::core::Value & | Val | ||
) | [protected] |
Appends a distributed variable value for a unit at the end of the previously added values for this variable
[in] | UnitPtr | a Unit |
[in] | VarName | the name of the variable |
[in] | Val | the added value of the variable |
void openfluid::ware::SimulationContributorWare::OPENFLUID_AppendVariable | ( | openfluid::core::Unit & | aUnit, |
const openfluid::core::VariableName_t & | VarName, | ||
const openfluid::core::Value & | Val | ||
) | [protected] |
Appends a distributed variable value for a unit at the end of the previously added values for this variable
[in] | aUnit | a Unit |
[in] | VarName | the name of the variable |
[in] | Val | the added value of the variable |
void openfluid::ware::SimulationContributorWare::OPENFLUID_AppendVariable | ( | openfluid::core::Unit * | UnitPtr, |
const openfluid::core::VariableName_t & | VarName, | ||
const double & | Val | ||
) | [protected] |
Appends a distributed double variable value for a unit at the end of the previously added values for this variable
[in] | UnitPtr | a Unit |
[in] | VarName | the name of the variable |
[in] | Val | the added value of the variable (double) |
void openfluid::ware::SimulationContributorWare::OPENFLUID_AppendVariable | ( | openfluid::core::Unit * | UnitPtr, |
const openfluid::core::VariableName_t & | VarName, | ||
const long & | Val | ||
) | [protected] |
Appends a distributed long variable value for a unit at the end of the previously added values for this variable
[in] | UnitPtr | a Unit |
[in] | VarName | the name of the variable |
[in] | Val | the added value of the variable (long) |
void openfluid::ware::SimulationContributorWare::OPENFLUID_AppendVariable | ( | openfluid::core::Unit * | UnitPtr, |
const openfluid::core::VariableName_t & | VarName, | ||
const bool & | Val | ||
) | [protected] |
Appends a distributed boolean variable value for a unit at the end of the previously added values for this variable
[in] | UnitPtr | a Unit |
[in] | VarName | the name of the variable |
[in] | Val | the added value of the variable (bool) |
void openfluid::ware::SimulationContributorWare::OPENFLUID_AppendVariable | ( | openfluid::core::Unit * | UnitPtr, |
const openfluid::core::VariableName_t & | VarName, | ||
const std::string & | Val | ||
) | [protected] |
Appends a distributed string variable value for a unit at the end of the previously added values for this variable
[in] | UnitPtr | a Unit |
[in] | VarName | the name of the variable |
[in] | Val | the added value of the variable (string) |
void openfluid::ware::SimulationContributorWare::OPENFLUID_BuildUnitsMatrix | ( | const openfluid::core::UnitClass_t & | UnitsClass, |
const unsigned int & | ColsNbr, | ||
const unsigned int & | RowsNbr | ||
) | [protected] |
Builds a ColsNbr x RowsNbr unix matrix with bi-directionnal connections
[in] | UnitsClass | the name of units class |
[in] | ColsNbr | the number of units on the X axis |
[in] | RowsNbr | the number of units on the Y axis |
void openfluid::ware::SimulationContributorWare::OPENFLUID_DeleteUnit | ( | openfluid::core::UnitClass_t | ClassName, |
openfluid::core::UnitID_t | ID | ||
) | [protected] |
Deletes a unit from the set of units if exists
[in] | ClassName | class name of the removed unit |
[in] | ID | ID of the added unit |
void openfluid::ware::SimulationContributorWare::OPENFLUID_InitializeVariable | ( | openfluid::core::Unit * | UnitPtr, |
const openfluid::core::VariableName_t & | VarName, | ||
const openfluid::core::Value & | Val | ||
) | [protected] |
Initializes a distributed variable value for a unit
[in] | UnitPtr | a Unit |
[in] | VarName | the name of the variable |
[in] | Val | the added value of the variable |
void openfluid::ware::SimulationContributorWare::OPENFLUID_InitializeVariable | ( | openfluid::core::Unit & | aUnit, |
const openfluid::core::VariableName_t & | VarName, | ||
const openfluid::core::Value & | Val | ||
) | [protected] |
Initializes a distributed variable value for a unit
[in] | aUnit | a Unit |
[in] | VarName | the name of the variable |
[in] | Val | the added value of the variable |
void openfluid::ware::SimulationContributorWare::OPENFLUID_InitializeVariable | ( | openfluid::core::Unit * | UnitPtr, |
const openfluid::core::VariableName_t & | VarName, | ||
const double & | Val | ||
) | [protected] |
Initializes a distributed double variable value for a unit
[in] | UnitPtr | a Unit |
[in] | VarName | the name of the variable |
[in] | Val | the added value of the variable (double) |
void openfluid::ware::SimulationContributorWare::OPENFLUID_InitializeVariable | ( | openfluid::core::Unit * | UnitPtr, |
const openfluid::core::VariableName_t & | VarName, | ||
const long & | Val | ||
) | [protected] |
Initializes a distributed long variable value for a unit
[in] | UnitPtr | a Unit |
[in] | VarName | the name of the variable |
[in] | Val | the added value of the variable (long) |
void openfluid::ware::SimulationContributorWare::OPENFLUID_InitializeVariable | ( | openfluid::core::Unit * | UnitPtr, |
const openfluid::core::VariableName_t & | VarName, | ||
const bool & | Val | ||
) | [protected] |
Initializes a distributed boolean variable value for a unit
[in] | UnitPtr | a Unit |
[in] | VarName | the name of the variable |
[in] | Val | the added value of the variable (bool) |
void openfluid::ware::SimulationContributorWare::OPENFLUID_InitializeVariable | ( | openfluid::core::Unit * | UnitPtr, |
const openfluid::core::VariableName_t & | VarName, | ||
const std::string & | Val | ||
) | [protected] |
Initializes a distributed string variable value for a unit
[in] | UnitPtr | a Unit |
[in] | VarName | the name of the variable |
[in] | Val | the added value of the variable (string) |
bool openfluid::ware::SimulationContributorWare::OPENFLUID_RemoveChildParentConnection | ( | openfluid::core::UnitClass_t | ClassNameChild, |
openfluid::core::UnitID_t | IDChild, | ||
openfluid::core::UnitClass_t | ClassNameParent, | ||
openfluid::core::UnitID_t | IDParent | ||
) | [protected] |
Removes a child-parent connection between two units
[in] | ClassNameChild | class name of the "child" unit |
[in] | IDChild | ID of the "child" unit |
[in] | ClassNameParent | class name of the "parent" unit |
[in] | IDParent | ID of the "parent" unit |
bool openfluid::ware::SimulationContributorWare::OPENFLUID_RemoveChildParentConnection | ( | openfluid::core::Unit * | ChildUnit, |
openfluid::core::Unit * | ParentUnit | ||
) | [protected] |
Removes a child-parent connection between two units
[in] | ChildUnit | pointer to the "child" unit |
[in] | ParentUnit | pointer to the "parent" unit |
bool openfluid::ware::SimulationContributorWare::OPENFLUID_RemoveFromToConnection | ( | openfluid::core::UnitClass_t | ClassNameFrom, |
openfluid::core::UnitID_t | IDFrom, | ||
openfluid::core::UnitClass_t | ClassNameTo, | ||
openfluid::core::UnitID_t | IDTo | ||
) | [protected] |
Removes a from-to connection between two units
[in] | ClassNameFrom | class name of the "from" unit |
[in] | IDFrom | ID of the "from" unit |
[in] | ClassNameTo | class name of the "to" unit |
[in] | IDTo | ID of the "to" unit |
bool openfluid::ware::SimulationContributorWare::OPENFLUID_RemoveFromToConnection | ( | openfluid::core::Unit * | FromUnit, |
openfluid::core::Unit * | ToUnit | ||
) | [protected] |
Removes a from-to connection between two units
[in] | FromUnit | pointer to the "from" unit |
[in] | ToUnit | pointer to the "to" unit |
void openfluid::ware::SimulationContributorWare::OPENFLUID_SetAttribute | ( | openfluid::core::Unit * | UnitPtr, |
const openfluid::core::AttributeName_t & | AttrName, | ||
const openfluid::core::Value & | Val | ||
) | [protected] |
Sets attribute for a unit
[in] | UnitPtr | a Unit |
[in] | AttrName | the name of the set attribute |
[in] | Val | the value of the set attribute |
void openfluid::ware::SimulationContributorWare::OPENFLUID_SetAttribute | ( | openfluid::core::Unit * | UnitPtr, |
const openfluid::core::AttributeName_t & | AttrName, | ||
const double & | Val | ||
) | [protected] |
Sets attribute for a unit, as a double
[in] | UnitPtr | a Unit |
[in] | AttrName | the name of the set attribute |
[in] | Val | the value of the set attribute |
void openfluid::ware::SimulationContributorWare::OPENFLUID_SetAttribute | ( | openfluid::core::Unit * | UnitPtr, |
const openfluid::core::AttributeName_t & | AttrName, | ||
const long & | Val | ||
) | [protected] |
Sets attribute for a unit, as a long integer
[in] | UnitPtr | a Unit |
[in] | AttrName | the name of the set attribute |
[in] | Val | the value of the set attribute |
void openfluid::ware::SimulationContributorWare::OPENFLUID_SetAttribute | ( | openfluid::core::Unit * | UnitPtr, |
const openfluid::core::AttributeName_t & | AttrName, | ||
const std::string & | Val | ||
) | [protected] |
Sets attribute for a unit, as a string
[in] | UnitPtr | a Unit |
[in] | AttrName | the name of the set attribute |
[out] | Val | the value of the set attribute |
void openfluid::ware::SimulationContributorWare::OPENFLUID_SetVariable | ( | openfluid::core::Unit * | UnitPtr, |
const openfluid::core::VariableName_t & | VarName, | ||
const openfluid::core::Value & | Val | ||
) | [protected] |
Sets a distributed variable value for a unit at the current time index
[in] | UnitPtr | a Unit |
[in] | VarName | the name of the variable |
[in] | Val | the added value of the variable |
void openfluid::ware::SimulationContributorWare::OPENFLUID_SetVariable | ( | openfluid::core::Unit * | UnitPtr, |
const openfluid::core::VariableName_t & | VarName, | ||
const double & | Val | ||
) | [protected] |
Sets a distributed double variable value for a unit at the current time index
[in] | UnitPtr | a Unit |
[in] | VarName | the name of the variable |
[in] | Val | the added value of the variable (double) |
void openfluid::ware::SimulationContributorWare::OPENFLUID_SetVariable | ( | openfluid::core::Unit * | UnitPtr, |
const openfluid::core::VariableName_t & | VarName, | ||
const long & | Val | ||
) | [protected] |
Sets a distributed double variable value for a unit at the current time index
[in] | UnitPtr | a Unit |
[in] | VarName | the name of the variable |
[in] | Val | the added value of the variable (long) |
void openfluid::ware::SimulationContributorWare::OPENFLUID_SetVariable | ( | openfluid::core::Unit * | UnitPtr, |
const openfluid::core::VariableName_t & | VarName, | ||
const bool & | Val | ||
) | [protected] |
Sets a distributed double variable value for a unit at the current time index
[in] | UnitPtr | a Unit |
[in] | VarName | the name of the variable |
[in] | Val | the added value of the variable (bool) |
void openfluid::ware::SimulationContributorWare::OPENFLUID_SetVariable | ( | openfluid::core::Unit * | UnitPtr, |
const openfluid::core::VariableName_t & | VarName, | ||
const std::string & | Val | ||
) | [protected] |
Sets a distributed double variable value for a unit at the current time index
[in] | UnitPtr | a Unit |
[in] | VarName | the name of the variable |
[in] | Val | the added value of the variable (string) |
